RunnTech Single-axis (Forward/Reverse) Joystick Speed Command by Potentiometer for Winch

News & Events
Product configuration: RT100-T-1-V1(10K)-02(89)-HD4-BT1R-M1
  • RT100: RunnTech 100 series industrial joystick controller;
  • T: mechanical spring return to neutral;
  • 1: single axis, forward/reverse movement;
  • V1: input: 24Vdc, output: -10Vdc…0…+10Vdc;
  • 10K: 10K Ohm conductive-plastic potentiometer with solid center tap;
  • 02(89): 2 directional contacts in Y axis;
  • HD4-BT1R: joystick grip top with 1 pushbutton;
  • M1: mounting dimension 56x56mm, central hole: 63mm;

RunnTech Single-axis (Forward/Reverse) Joystick Speed Command by Potentiometer for Winch

RunnTech 2-axis Industrial Joystick with 2 Proportional Hall Sensor Thumbwheel Controller

News & Events
Product configuration: RT01-T-3-V6(5K)-02(55)-HD10a9-[W100L-T-HV2]*2-M4
  • RT01: RunnTech 01 series joystick controller;
  • T: spring return device (automatically return to center);
  • 3: dual axis joystick, omenidirectional (full direction) movement;
  • V6: input: 24VDC, output: 0…+5VDC;
  • 02(55): each axis with 2 NC switches in center postion;
  • HD10a9: RunnTech joystick grip with deadman button;
  • [W100L-T-HV2]*2: 2 proportional thumbwheel controllers (0.5…2.5…4.5V output);
  • M4: mounting dimension 64x64mm, central hole: 84mm;

RunnTech 2-axis Industrial Joystick with 2 Proportional Hall Sensor Thumbwheel Controller

RunnTech Single Axis Friction Joystick Controller with 10k Ohm Potentiometer for Control Winch

News & Events
Product configuration: RT100-M-1-P1(10K)-02(89)-HD1-M1
  • RT100: RunnTech 100 series industrial joystick controller;
  • M: friction brake;
  • 1: single axis movement (Y axis, astern/ahead);
  • P1: 0%…100% analog output;
  • 10K: 10K Ohm conductive-plastic potentiometer with solid center tap (with dead zone);
  • 02(89): 2 directional switches in each axis;
  • HD8: grip handle;
  • M1: mounting dimension 56x56mm, central hole: 63mm.

RunnTech Single Axis Friction Drive Joystick with 10k Ohm Potentiometer for Control Winch

The Working Principle Of Potentiometer

News & Events

The potentiometer is a type of resistor used to adjust the voltage in a circuit. It typically consists of a movable sliding contact and a fixed resistor. Its operation is based on the principle of voltage division. Specifically, when the potentiometer is connected to a circuit, current flows through the resistor. Applying a voltage across…

The Differences Between Industrial Joystick Controllers and Gaming Controllers

News & Events

Purpose: Industrial joysticks are designed for industrial control and operation, such as in machinery and automation equipment. Gaming controllers are designed for electronic gaming and entertainment purposes. Design and Structure: Industrial joysticks are typically larger, heavier, and more rugged, with a focus on durability and functionality. Gaming controllers are lighter, more ergonomic, and designed for…

The History of Industrial Joystick Controller

News & Events

The industrial joystick is a human-machine interaction device applied to various electromechanical devices. It utilizes potentiometers or Hall sensors to perceive hand movements on the joystick, generating corresponding electrical signals to control the device’s direction, speed, and distance. Before the advent of industrial joysticks, there were two other types of control levers in history. In…

The Principle Of Industrial Joystick Controller

News & Events

The principle of an industrial joystick is based on sensor technology and electronic control systems. Here is the basic working principle of an industrial joystick: Sensor detects joystick movement: The industrial joystick is equipped with potentiometers or Hall sensors to sense the user’s movements on the joystick. These sensors can detect the position, orientation, and…
